Fire Protection · F-2GAQW

Vertical Pipe Support Detail

Elements

Connections

About this detail

A vertical pipe riser is supported by a clamp assembly secured with hex head bolts, nuts, and washers on opposing sides. Dimensions A, B, and C vary according to the pipe diameter and specify the overall clamp width, bolt spacing, and offset. For 1-inch through 3-inch pipes, use 3/8-inch nuts and bolts. For 4-inch through 6-inch pipes, use 1/2-inch nuts and bolts. For an 8-inch pipe, use 5/8-inch nuts and bolts.
