Cable tray suspension utilizes a minimum 10 gauge wire spaced at four feet on center. The wire attaches to overhead concrete or metal structures using shot pins and clips similar to detail D2/A10.40. Connections require a minimum of three tight turns to secure the wire properly.
MIN. 10 GAUGE WIRE AT 4'-0" ATTACH TO CONCRETE/METAL WITH SHOT PINS AND CLIPS SIM D2/A10.40 (MIN. (3) TIGHT TURNS)
