E-ZP9TV — Receptacle Identification

Electrical · E-ZP9TV

Receptacle Identification

Units: imperial
Sheet: E-500
Discipline: Electrical

Text on the drawing

WIDTH AS REQUIRED 3/16" "PANEL NAME":"CIRCUIT NUMBER" 1 BRANCH CIRCUIT CONDUCTOR LABELING 12 10 8 6 4 2 11` 9 7 5 3 1 TYPICAL: LINE CONDUCTORS 11` OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON OFF ON PANEL ENCLOSURE TYPICAL: POLE NUMBER LABEL ON WIRE (APPLIED BY THIS CONTRACTOR) TYPICAL: BRANCH BREAKERS PER PANEL SCHEDULES 3

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
