A downlead conductor and equipment grounding conductor tie into a ground ring counterpoise via exothermic welds set 760mm below grade typically. A vertical ground rod connects to the ground ring using an exothermic weld fitting. All conductor intersections and rod connections utilize exothermic welding to ensure a permanent electrical bond.
760MM BELOW GRADE (TYP) DOWNLEAD CONDUCTOR EXOTHERMIC WELD EQUIPMENT GROUNDING CONDUCTOR GROUND RING (COUNTERPOISE) GROUND ROD SCALE NTS B4 BONDING EXHAUST STACK
