A single-sided, single-tier pre-galvanized steel J-hook, comparable to the B-Line series BCH with sizes varying from 3/4 inch to 1-5/16 inches, is secured directly to an 18-gauge metal stud spaced at 16 inches on center. The J-hook is fastened using one number 12 self-drilling self-tapping screw spaced every 48 inches nominal. The wall assembly is finished with 5/8-inch Type X gypsum board on both sides.
ATTACH J-HOOK TO METAL STUD WITH (1) #12 SDST SCREW EVERY 48" NOMINAL. CABLE RETAINER CLIP SINGLE SIDED, SINGLE TIER, PRE-GALVANIZED STEEL J-HOOK AS B-LINE SERIES "BCH". SIZE VARIES FROM 3/4" TO 1-5/16". 5/8" TYPE X GYPBOARD 18-GA. METAL STUDS AT 16" O.C.
