An LM-MSTP network wire routes through conduit or cable ties to connect additional network bridges or a segment manager. The twisted pair conductors terminate at the screw terminals of the network bridge unit.
NETWORK BRIDGE LM-MSTP NETWORK WIRE TO ADDITIONAL NETWORK BRIDGES OR SEGMENT MANAGER
