Electrical conduits pass through fire-rated walls and floors constructed per architectural drawings. An appropriately sized hole accommodates the conduit while leaving space for a proper firestop compound installation. An approved firestop compound fills the annular space around the conduit to seal and protect the rated assembly. A conduit support is provided at the floor surface as required.
WALL PENETRATION FLOOR PENETRATION FIRE RATED FLOOR DRAWINGS SEE ARCHITECTURAL CONDUIT ELECTRICAL AS REQUIRED CONDUIT SUPPORT CONDUIT ELECTRICAL CONTRACTOR TO INSURE APPROPRIATE SIZE HOLE TO ALLOW FOR PROPER INSTALLATION OF COMPOUND APPROVED FIRESTOP COMPOUND USED TO SEAL AND PROTECT WALLS OR FLOORS AS REQUIRED FIRE RATED WALL SEE ARCHITECTURAL DRAWINGS
