Two Category 6A cables route through a one-and-one-quarter-inch ceiling-mounted conduit into a four-inch square box mounting plate. A surface-mounted two-position box houses two Category 6A jacks, connected by two Category 6A patch cords.
SURFACE MOUNTED 2 POSITION BOX WITH 2 CAT 6A JACKS, TYP. (2) CAT 6A PATCH CORDS, TYP. CEILING MOUNT 1.25" CONDUIT, TYP. (2) CAT 6A CABLES, TYP. 4" SQUARE BOX MOUNTING PLATE
