Sludge Blending Tank Mixer 1 Motor Control Diagram

About this detail

Electrical loop diagram detailing the power, control, and instrumentation connections for Sludge Blending Tank Mixer 1. The VFD-60107 feeds power from MCC61C1 through specified conduit sizes and conductor counts. Local control stations LCS-60111 and LCS-60113 interface with motor-operated valves and associated panels connected to PLC-70 I/O drop 5. Junction boxes and sensor inputs including MSH-60105 and TSH-60105 complete the instrumentation loop.
