Duplex receptacles and communications receptacles are positioned either above the countertop with a maximum height of forty-six inches, requiring verification of backsplash height, or below the countertop with a minimum clearance of sixteen inches. Countertop grommets provide wire routing access for devices located below the surface. A typical window location is referenced relative to the above-counter receptacle placement.
2 DUPLEX RECEPTACLE DUPLEX RECEPTACLE COUNTER - TYPICAL ABOVE RECEPTACLES ABOVE OR BELOW COUNTER WINDOW OR COMMUNICATIONS RECEPTACLE COUNTER TOP GROMMET COMMUNICATIONS RECEPTACLE ±46" MAX (VERIFY HEIGHT OF BACKSPLASH) 16" MIN
