Duplex receptacles and communications receptacles are positioned relative to the counter top and window locations. Above-counter outlets maintain a maximum height of forty-six inches, requiring verification of the backsplash height. Below-counter outlets maintain a sixteen-inch minimum clearance from the finished floor. Counter tops include optional grommets for cord management with adjacent communications outlets.
2 DUPLEX RECEPTACLE DUPLEX RECEPTACLE COUNTER - TYPICAL ABOVE RECEPTACLES ABOVE OR BELOW COUNTER WINDOW OR COMMUNICATIONS RECEPTACLE COUNTER TOP GROMMET COMMUNICATIONS RECEPTACLE ±46" MAX (VERIFY HEIGHT OF BACKSPLASH) 16" MIN
