An interior photograph documents existing electrical infrastructure within a utility space, including motor control centers MCC61C1 and MCC61C2, a transformer, panel PNL61LA, and a PLC drop. Overhead space heaters and associated cable and conduit runs connect to the wall-mounted and floor-standing equipment. Additional components include cathodic protection equipment and a generator receptacle.
EXISTING SPACE HEATER EXISTING CABLE AND CONDUIT EXISTING TRANSFORMER EXISTING MCC61C2 EXISTING CONDUIT k I* r» '' \ m EXISTING CATHODIC PROTECTION EQUIPMENT EQUIPMENT (TYP OF 3) EXISTING GENERATOR RECEPTACLE EXISTING PLC 6 DROP 5 EXISTING MCC61C1 EXISTING PNL61LA D-20-101 PHOTO A NO SCALE
