A metallic conduit with a minimum diameter of one-half inch penetrates a one-hour or two-hour fire-rated gypsum board wall framed with wood or steel studs. The annular space around the conduit is sealed with a bead of three-M fire barrier moldable putty or CP twenty-five caulk. The firestop assembly is tested up to four hours in accordance with ASTM E eight-fourteen, UL fourteen-seventy-nine, and CAN/ULC S one-fifteen. Actual procedures depend upon the annular space between the pipe and the wall opening, requiring adherence to manufacturer instructions.
WOOD OR STEEL STUD 1 OR 2 HOUR FIRE RATED GYPSUM BOARD WALL BEAD OF 3M FIRE BARRIER MOLDABLE PUTTY CP 25 CAULK OR MP 1/2" MINIMUM DIAMETER METALLIC CONDUIT NOTE: TYPICAL DETAILS SHOWING GENERAL FIRE STOPPING PROCEDURE. ACTUAL PROCEDURE DEPENDS UPON ANNULAR SPACE BETWEEN PIPE AND/OR INSULATION AND OPENING. FOLLOW MANUFACTURER'S INSTRUCTIONS. FIRESTOP TESTED UP TO 4 HOURS IN ACCORDANCE WITH ASTM E 814 (UL 1479) & CAN/ULC S115
