An electrical continuation diagram details a one-inch conduit containing one 4/0 American Wire Gauge ground conductor routed from a switchboard to concessions. The ground line connects to the neutral and ground bus bars within the panel and extends to a ground symbol. A spare circuit feed is indicated with continuation routing to sheet E00-020 for switchboard SWB1088BC.
G N 1"C.-1#4/0AWG GND EO FOR CONCESSIONS SPARE SEE SHEET E00-020 FOR CONTINUATION POWER EO 001 SWB1088BC
