This electrical diagram details a 30-ampere, 3-pole non-fused safety switch rated at 8.3 kilowatts, 208 volts, 3-phase. The unit connects to circuit designations 3L-31, 33, 35 through a three-quarter-inch conduit containing three number 10 conductors and one number 10 ground conductor. Power is supplied via a 30-ampere, 3-pole breaker. An identical second switch configuration connects to circuits 3L-37, 39, 41 with matching conduit and conductor specifications.
