Scrubber no. 3 fan 78-EF-502-03 exhausts through acoustic enclosure fan no. 3 to the atmosphere. The system incorporates pressure indicators PI 78-500-03 and PI 78-503-03, damper DMP-78-501-61, and temperature and vibration switches TSH and VSH 78-501-03.
PI PI 78-OCU-501-03 SCRUBBER NO. 3 FAN 78-EF-502-03 ACOUSTIC ENCLOSURE FAN NO. 3 ATMOSPHERE DMP-78-501-61 TSH VSH
