A lay-in troffer light fixture is suspended in a lay-in tile ceiling system using number twelve steel wire secured to the overhead concrete structure. The wire anchors to the concrete ceiling using a three-quarter-inch pin and angle clip. Four lay-in and troffer light fixture support clips, specifically Caddy 515 or 515A or equivalent, are provided per fixture.
LAY-IN AND TROFFER LIGHT FIXTURE SUPPORT CLIP (CADDY 515 OR 515A TO SUIT APPLICATION OR EQUIVALENT). PROVIDE 4 CLIPS PER FIXTURE. LAY-IN TROFFER LAY-IN TILE CEILING ANCHOR TO CONCRETE CEILING USING 3/4" PIN & ANGLE CLIP (TYP.) #12 STEEL WIRE (TYP.) ANCHOR TO CONCRETE CEILING
