A dry ash supervac cyclone separator is installed in the mechanical space with six inch ash piping routed above. An existing cogeneration cable tray runs horizontally near the equipment. The unit is supported from the floor adjacent to existing structural columns and interior walls.
<£> 6" ASH (TYP 4) EXISTING COGEN CABLE TRAY DRY ASH SUPERVAC CYCLONE SEPARATOR ■ r ( - ■■ BFn I - 4 .* D-J2-W1^PH0T0 A NO SCALE
