An underground communications duct bank is installed below finished grade with a minimum depth of thirty-six inches. The assembly consists of four-inch Schedule 40 PVC conduits embedded in a six-inch sand bed, spaced three inches apart typically. An underground line warning tape is placed six to nine inches below the finished grade.
3" (TYP.) 4" SCHED 40 PVC CONDUIT TYPICAL FINISHED GRADE UNDERGROUND LINE WARNING TAPE (6-9" BELOW GRADE) 6" SAND 36" MIN SCALE: NTS ES501 D6 UNDERGROUND COMMUNICATIONS DUCT BANK BELOW ROADWAY
