Surface mounted panels weighing up to two hundred pounds are secured to either a cold-formed metal stud wall or a masonry wall. The metal stud mounting utilizes number twelve hex washer head self-tapping screws spaced at six inches on center typical. The masonry mounting configuration refers to structural detail 8/S9.01 for proper anchorage. Both assemblies accommodate heavy surface-mounted units while transferring loads back to the primary wall construction.
MASONRY WALL MASONRY MOUNTING PANEL (MAX. WEIGHT 200 LBS) #12 H.W.H. TEXS/5 SELF TAPPING SCREW METAL STUD WALL AT 6" O.C. (TYPICAL) METAL MOUNTING PANEL (MAX. WEIGHT 200 LBS) REFER TO STRUCTURAL DETAIL 6/S9.02 REFER TO STRUCTURAL DETAIL 8/S9.01 8/S9.01
