A bronze cross bar wraps around the pipe and secures with bronze hex nuts and lockwashers on each threaded end. A single-hole compression lug from the Thomas & Betts series 54104 mounts onto the stud of the cross bar. An additional lockwasher and nut fasten the compression lug securely in place. This standard water pipe ground clamp assembly applies to all plumbing, HVAC metal piping, and sprinkler piping systems.
LOCKWASHER AND NUT SINGLE HOLE - COMPRESSION LUG T & B SERIES 54104 BRONZE CROSS BAR BRONZE HEX NUT (2) WITH LOCKWASHER NOTES: A. THIS DETAIL APPLIES TO ALL PLUMBING AND HVAC METAL PIPING AS WELL AS SPRINKLER PIPING. B. STANDARD WATER PIPE GROUND CLAMP ASSEMBLY T & B CAT. NO. 3902 BU SERIES.
