The fire alarm horn strobe is mounted at an elevation between 80 inches minimum and 96 inches maximum above the floor line. The fire alarm pull station is installed at a maximum height of 48 inches above the floor line, with receptacles or lower devices set to a 16-inch minimum clearance. Dimensions are measured from the finished floor line to the centerline of the electrical devices.
80" MINIMUM 96" MAXIMUM 48" MAX. 16" MIN. FLOOR LINE FIRE ALARM HORN/STROBE FIRE ALARM PULL STATION
