An engraved electrical equipment nameplate is fabricated from green Gravopoly material numbered seventeen hundred forty-two with a minimum height of two and three-quarter inches and a variable width of five inches minimum. The layout dictates specific text lines designating upstream source feeds and downstream equipment designations. Vertical and horizontal edge clearances establish exact text alignment and fastener hole locations relative to the plate perimeter.
FED FROM: HUPS-01 HUDPP-01 FEEDS: HUPP-1.2 GREEN GRAVOPOLY #17442 WIDTH AS REQUIRED. 5" MINIMUM 2 3/4" MIN. WIDTH AS REQUIRED. 5" MINIMUM 2 3/4" MIN. 1/4" 1/4" 1/4" 1/4" 3/8" 3/8" 3/8" 3/8" 1/4" 1/4" 1/4" 1" 1" FED FROM: HSDB-01 HUPS-01 FEEDS:
