Electrical · E-V35QC

Typical Lobby and Break Room Lighting Control Wiring Diagram

Elements

About this detail

An electrical wiring diagram details a lighting control system utilizing an LMRC-212 dimming room controller connected to 120/277V unswitched hot, neutral, and earth ground. An ELCU-200 remote activation unit handles emergency lighting connections with black and white 12AWG wire for power in and neutral, and red 12AWG wire for emergency power out. The sequence of operation specifies that upon normal power loss, the ELCU-200 bypasses the room controller to force emergency fixtures on at 100 percent brightness. Additional components include an LMPL-101 plug load controller, controlled and uncontrolled receptacles, LMDM-101 and LMDW-102 wall switches, and an LMBC-300 network bridge utilizing Cat5e or LMRJ pre-terminated cables for DLM device communication and 0-10VDC dimming ballast control.
