An electric water cooler mounts to the wall, receiving power through electrical metallic tubing conduit. Flexible conduit extends from the electrical metallic tubing to the electric water cooler chiller enclosure for the final power connection. Field verify the unit mounting height and coordinate with architectural plans and the plumbing contractor prior to installation.
