A top deck stabilizer component has an overall length of 8.28 inches and a width of 8.59 inches. Welded connections utilize 1/8-inch fillet welds applied to both sides. Mounting plates and brackets are secured with standard fasteners as indicated by the callouts. The assembly is detailed across top, side, and end views showing spacing dimensions of 1.25 inches and 1.50 inches.
8.28 1.50 8.59 1.25 (2x 0.18) 0.56 10 D7 4 D8A 3 D8A 1/8 1/8 1/8 1/8 TYP BOTH SIDES TOP DECK STABILIZER 2 D8A A =— 7 i EEEE EET Le e0 0 0 i i i i E 9
