This electrical conduit transition details the underground run transitioning from a PVC Schedule 40 conduit to a galvanized rigid steel conduit elbow wrapped with a 3 mil minimum electrical tape with a 1/2 width overlap. The rigid steel conduit continues upward through the finished grade level. A rigid steel conduit coupling and plug are installed on spare conduits. The coupling location must be coordinated to match the location of future equipment where required, and additional rigid steel conduit risers are provided as needed for deeper routed conduits.
NOTES: COORDINATE COUPLING LOCATION TO MATCH LOCATION OF FUTURE EQUIPMENT WHERE REQUIRED. GALVANIZED RIGID STEEL CONDUIT ELBOW. PROVIDE RIGID STEEL CONDUIT RISER AS REQUIRED FOR DEEPER ROUTED CONDUITS. PVC SCHEDULE 40, SIZE AS REQUIRED ON DRAWINGS 3 MIL MINIMUM ELECTRICAL TAPE WITH 1/2 WIDTH OVERLAP RIGID STEEL CONDUIT RISER. RIGID STEEL CONDUIT COUPLING & PLUG FOR SPARE CONDUIT(S). FINISHED GRADE.
