Bi-Level Ceiling Sensor Single Circuit Wiring Diagram

Elements

About this detail

A ceiling-mounted vacancy or occupancy sensor connects to a relay pack and a two-gang single-pole single-throw switch or key switch, which controls two normal lighting zones from a normal power source. The sequence of operation specifies auto-on and auto-off for occupancy sensing or manual-on and auto-off for vacancy sensing in both zones, with all lights shutting off at a predetermined time when the area is vacated. Detail notes specify providing an additional single-pole single-throw switch or key switch for additional zones as required per plan.
