A surface-mounted security camera is anchored to the wall with a one-inch conduit routing back to an accessible ceiling space equipped with an insulated bushing. The internal cable features a laminated label placed three to four inches from the termination point. Excess cable coil is supported directly by the building structure using typical hanging hardware.
LAMINATING CABLE LABEL 3"-4" FROM TERMINATION CABLE COIL SUPPORTED BY BUILDING STRUCTURE (TYP) 1" CND BACK TO ACCESSIBLE CEILING SPACE W/INSULATED BUSHING
