Electrical · E-SRCT5

Motor Control Center One-Line Diagram

Materials

Elements

About this detail

Electrical one-line diagram showing a 600A, 480V, 3-phase, 3-wire, 60Hz bus distribution system with 65KAIC rating. The diagram details multiple feeder circuits connected to motor control center units, junction boxes, and equipment feeds with specified wire sizes, conduit diameters, and circuit breaker ratings. General notes require the contractor to field verify existing equipment controls, reference specification 260511, and match MCC nameplate wording from the diagram.
