This one-line diagram details the electrical distribution and connections for the Cake Pump 4 control panel (PNL-73195), incorporating PLC-CFG4 I/O drop 2 on the second floor in area F. The drawing references associated panels including centrifuge 4 control panel PNL-74049, cake pump 4 HPU control panel PNL-72423, and maintenance box PNL-73197. Power feeds include standard 120VAC and 120VAC UPS circuits.
CAKE PUMP 4 CONTROL PANEL (PNL-73195) PLC-CFG4 I/O DROP 2 ONE-LINE DIAGRAM SCB 2ND FLOOR - AREA F MAINT BOX PNL-73197 CAKE PUMP 4 HPU CONTROL PANEL PNL- 72423 CENTRIFUGE 4 CONTROL PANEL PNL- 74049 120VAC (UPS) 120VAC 120VAC
