Electrical · E-SME64

Wiring Harness Subpanel

About this detail

An electrical subpanel add-on kit is provided to supply a service disconnect and fusing for an FAA obstruction light. The assembly incorporates one auxiliary contact, one 600-volt 85-ampere terminal block, a small red divider, and two end barriers. A touch-safe single-pole fuseholder with a KTK-5 fuse is connected via female connectors and 14 to 18 gauge protective sleeving with an inner diameter of 0.275 inches. Terminal block marker strips labeled "N" are included. All terminal block screws are torqued to specified values.
