A new three-quarter-inch by eight-foot by four-foot fire-rated plywood backboard is mounted on typical metal studs with existing five-eighths-inch gypsum board. The backboard is secured using number twelve sheet metal screws spaced at eight inches on center with three-quarter-inch flat washers in a staggered bolt pattern. An angle bracket supports the assembly, and a cable runway ladder racking is positioned at eighty-four inches above finished floor with triangle mounting brackets. An equipment rack is integrated into the wall space.
8' 7'-1'' 7' 19'' EQUIPMENT RACK TRIANGLE MOUNTING BRACKET METAL STUDS (TYP.) (N)3/4"Wx8'Hx4"L FIRE RATED PLYWOOD. MT+2" AFF. (E)5/8" GYP. BOARD (TYP.) (CABLE RUNWAY) LADDER RACKING @84'' AFF PROVIDE AND INSTALL (MIN.) #12 SMS @ 8" O.C. WITH 3/4" FLAT WASHER. STAGGER BOLT PATTERN. ANGLE BRACKET 4'
