A service cable attaches to a vertical positioning bracket secured with a bracket and slotted steel angle or 1 5/8 inch by 1 5/8 inch C-channel. The cable positioning brackets utilize part numbers 420-3100 or 402-7810 to align the service cable along the structural framing. The horizontal support consists of a slotted steel angle or alternatively a 1 5/8 inch by 1 5/8 inch C-channel.
1 5/8" x 1 5/8" C-CHANNEL SERVICE CABLE CABLE POSITIONING BRACKET (420-3100 OR 402-7810) BRACKET SLOTTED STEEL ANGLE OR 1 5/8 x 1 5/8" C-CHANNEL OPTION 2
