An operable louver assembly connects to an aluminum glazing extrusion positioned above a glass pane. A rolled transom formed from a 6-inch by 2-inch hollow structural section supports the assembly via a steel anchor bracket. Wiring runs along the horizontal extrusion and through the framing members. A face cap finishes the exterior of the aluminum glazing extrusion aligned with the face of the glass.
FACE OF GLASS ALUMINUM GLAZING EXTRUSION FACE CAP HSS 6"X2" ROLLED TRANSOM OPERABLE LOUVER ASSEMBLY 1 1/2" 1" 3/8" STEEL ANCHOR BRACKET WIRING WIRING ON HOR. EXTRUSION
