E-S685Z — 3. Speaker Voltage Switch

Electrical · E-S685Z

3. Speaker Voltage Switch

About this detail

This electrical detail shows the internal terminal and switch layout for a Genesis outdoor speaker of the WG4 series. Callouts identify the wattage switch, wire slot, and speaker voltage switch used for setting operational parameters during installation.

1. WATTAGE SWITCH 2. WIRE SLOT 3. SPEAKER VOLTAGE SWITCH SPKR. SPKR. SPKR. SPKR.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
