An inverter and battery cabinet is shown with a maximum weight of 3,100 pounds. Conduit knockouts with an outside diameter of 0.875 inches are located on the sides of the enclosure. Bottom entry is also available for routing electrical raceways into the unit.
INVERTER/BATTERY INVERTER/BATTERY CABINET MAX. WEIGHT: 3100 Lbs Y X Z 3R CONDUIT LOCATION DETAIL. TYP. BOTH SIDES 0.875" OD CONDUIT KNOCKOUTS CONDUIT KNOCKOUTS ON SIDES BOTTOM ENTRY AVAILABLE
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
