Electrical · E-RJYM6

Conveyor and Valve Control Wiring Diagram

About this detail

Electrical one-line diagram detailing the power distribution and control wiring for ash conditioning conveyors and cake pump valves. Variable frequency drives VFD-79220 and VFD-79221 connect to motor starter disconnects, local control stations, and emergency stop switches. Conductor sizes, conduit diameters, and junction box designations are specified for each motor feed and control loop. Motorized valves V-79216 and V-79217 connect with associated Programmable Logic Controller input/output drops and panel feeds.
