Acceptable and unacceptable conduit bends indicate proper installation criteria for electrical raceways. The acceptable condition requires a minimum eight-inch radius with a ninety-degree angle. Conditions showing less than an eight-inch radius or an angle less than ninety degrees are marked not acceptable.
(MIN) ACCEPTABLE NOT ACCEPTABLE 8" RADIUS MIN. LESS THAN 8" RADIUS 8" RADIUS NOT ACCEPTABLE 90.00° 90.00° LESS THAN 90°
