Electrical · E-RA2S5

Polymer Feed Tank Instrumentation and Control Diagram

About this detail

An electrical schematic and connection diagram details the instrumentation, level transmitters, high-level switches, and motorized valves for polymer feed tanks 1 and 2. Control wiring circuits run to panels PNL-73708, PNL-73709, and PNL73436, specifying conductor counts, wire sizes, and conduit diameters such as two-wire number 12 with ground in three-quarter-inch conduit and shielded twisted pairs. Component tags identify polymer feed tank 1 influent valve V-73426, effluent valve V-73427, level indicator LIT-73432, and high level switch LSH-73432, alongside corresponding elements for polymer feed tank 2 including valves V-73428 and V-73429, level indicator LIT-73433, and high level switch LSH-73433.
