An industrial-duty cord reel with a positive-stop locking ratchet and twenty feet of three-conductor number ten Type SO cord is rigidly supported from the structural girder. An adjustable ball stop positions the drop cord, terminating in a Kellum grip and receptacle. The entire assembly provides drop-down power and data connectivity from overhead structure.
RECEPTACLE KELLUM GRIP - HUBBELL ADJUSTABLE BALL STOP CORD REEL, INDUSTRIAL DUTY TYPE WITH 20 FEET 3#10 TYPE 'SO' CORD AND POSITIVE-STOP LOCKING CORD RATCHET, WOODHEAD TYPE '9242' OR APPROVED EQUAL. RIGIDLY SUPPORT FROM STRUCTURE GIRDER 'SO' CORD 24" SCALE: NTS VOICE/DATA ROUGH-IN DETAIL 9
