A standard faceplate houses white Category 6A RJ-45 inserts typically installed for network drops. A designated label area at the top displays an example station number.
CAT 6A, RJ-45 INSERT, WHITE, TYP LABEL, STATION NUMBER (EXAMPLE ONLY) FACE PLATE 01 02 101-102-1 03 04
