E-QRAH9 — Typical Display and TV Mounting

Electrical · E-QRAH9

Typical Display and TV Mounting

Materials

Gypsum / Drywall

Elements

About this detail

Wall-mounted display installation within a framed gypsum board partition utilizing low-voltage boxes and an optional one hundred twenty volt raceway. The wall display low-voltage box is specified per plan with two typical locations. The mounting assembly coordinates electrical power and low-voltage data pathways within the stud cavity.

OPTIONAL 120V RACEWAY SECTION WALL DISPLAY LV BOX 'TV-B#' PER PLAN (TYP OF 2). PUSH PUSH
