Electrical · E-QNZS2

LAWA MPOE Room Headhouse Electrical Distribution Diagram

About this detail

An uninterruptible power supply unit rated at thirty kilovolt-amperes with a four-hundred eighty-volt input and a two-hundred eight over one hundred twenty-volt three-phase four-wire output feeds and receives power through electrical panels. Panel EDP1101XLI is rated at two hundred twenty-five amperes, two hundred eight over one hundred twenty volts, three-phase, four-wire, with a ten kiloampere interrupting capacity and a one-hundred ampere three-pole breaker. Panel EDP1102XHI is rated at two hundred twenty-five amperes, four hundred eighty over two hundred seventy-seven volts, three-phase, four-wire, with a forty-two kiloampere interrupting capacity and a two-hundred twenty-five ampere three-pole breaker. Both panels are located in the LAWA MPOE room headhouse.
