Electrical Switchboard One-Line Diagram with Transformer and Distribution Panels

About this detail

An existing 277/480-volt, three-phase, four-wire switchboard with a 600-ampere bus and 65KAIC rating feeds multiple circuits including an existing HAC1 panel through a 2 1/2-inch conduit with four 4/0 conductors and one #2 ground within a thirty-foot run. A transformer designated as T-P16 provides 75 kilovolt-amperes stepped down from 480V to 120/208V, connected via a 1 1/4-inch conduit with three #2 conductors and one #6 ground, feeding panel PP16 with a transient voltage surge suppressor. Panel PP16 further feeds a new spare panel PP17 through a short run under ten feet with a TVSS and equipment ground.
