An electrical distribution diagram shows a 112.5kVA 480-120/208V transformer feeding two 120/208V 400A 10KAIC distribution panels designated QBL2A and QBL2B. Both panels include surge protective devices. A 3 horsepower jockey pump motor controller connects to the system via a separate circuit.
M 112.5KVA 480-120/208V XFMR-QTX2A 5 SPD SPD QBL2A 120/208V 400A 10KAIC QBL2B 120/208V 400A 10KAIC CUP JOCKEY PUMP CONTLR (3 HP) F40T
