Wiring diagram illustrating the electrical connections for twenty kilovolt-ampere uninterrupted power supply units labeled EDP2092XLI, EDP2093XHI, EDP2101XLI, and EDP2102XHI. The diagram details ground and neutral connections routed between the uninterruptible power supply units and associated electrical distribution panels.
20KVA UPS EDP2101XLI N G 1 2 G EDP2102XHI N G 1 2 G 20KVA UPS EDP2092XLI N G 1 2 G EDP2093XHI N G 1 2 G G G
