This electrical diagram outlines the distribution layout and circuit breaker specifications for the mezzanine level. It details a seventy-five kilovolt-ampere transformer feeding a four hundred eighty to one hundred twenty or two hundred eight volt system through designated conduit and grounding conductors. Individual three-pole breaker circuits ranging from twenty to four hundred amperes connect to downstream equipment including designated electrical service connections. Conduit sizes, wire gauges, and spare breaker locations are explicitly designated along each feeder path.
"T-MCM1" 75KVA 480V- 120/208V 1"C-1#2 GRD. 20 SPACE (E) (E) (E) ESC. G203 1 1/4"C-3#4 & 1#6 GRD. 1 1/4"C-3#4 & 1#6 GRD. 1 1/4"C-3#4 & 1#6 GRD. ESC. G204 ESC. G303 (E) (E) (E) (E) SPARE E E E MEZZANINE LEVEL 100AT 100AF 3P 12 20AT 30AF 3P 13 40AT 60AF 3P 14 100AF 90AT 3P 15 100AF 70AT 3P 16 100AF 70AT 3P 17 100AF 70AT 3P 18 400AF 400AT 3P 19
