A junction box is recessed within the wall cavity against a stud or provided with supplementary support as required. Conduits route from the junction box to local devices typically, with main conduit runs routing to a low-voltage cable tray or as indicated on the floor plans. The assembly is oriented with the protected side clearly designated in plan view.
ROUTE CONDUIT TO LOW-VOLTAGE CABLE TRAY OR AS INDICATED ON THE FLOOR PLANS INSTALL J-BOX AGAINST STUD OR PROVIDE SUPPORT AS REQUIRED J-BOX RECESSED IN WALL ROUTE CONDUITS TO LOCAL DEVICES AS INDICATED, TYPICAL PROTECTED SIDE PLAN VIEW
