A quarter-inch thick, eighteen-inch long copper ground bar is mounted to a steel column using fasteners and rigid steel conduit nipples as spacers. Burndy Type KC Servit post grounding connectors attach to drilled holes in the bar. A five-hundred MCM cable is cadwelded to both the steel column and the ground bar. A jumper cable runs from the grounding bushing to the copper bar where enclosed in conduit, with quantities and sizes specified on the plan.
3" 3" 3" 1" 2" 4" 2" TO STEEL COLUMN 500MCM CADWELD STEEL COLUMN SECURE TO AND SIZE AS SHOWN ON PLAN ENCLOSED IN CONDUIT. QUANTITY BUSHING TO COPPER BAR WHERE JUMPER CABLE FROM GROUNDING GROUNDING CABLE. PROVIDE (RIGID STEEL CONDUIT NIPPLE) FASTENER AND SPACER GROUNDING CONNECTOR DRILLED HOLE WITH TYPE KC SERVIT POST GROUNDING CONNECTOR, BURNDY COPPER x 18" LONG GROUND BAR, 1/4" THK. STEEL COLUMN AND GROUND BAR
